Scope of work:
This is an ongoing project that evolves over time, adapting to technical variations and different quantities of hardware it needs to accommodate.
As the project progresses, it is continuously evaluated and adjusted to meet changing requirements and specifications.
Project constraints:
The case should not be waterproof, but rather leakproof, capable of preventing water from entering the internals
while still maintaining adequate ventilation for the PC placed inside.
QTY hardware:
•Intel Nuc-sized PC(fully internal)
•Gobo Projector(outside)
•Wi-Fi outdoor camera(outside)
•USB 4G hotspot Huawei(inside, but technically counts as outside)
All the project constraints serve as features that shape the final case design.
The only internal component is a computer; all other hardware is placed outside in such a way
that the gobo projector beam can be aligned with the outdoor camera view.
Software: Autodesk Fusion 360
3D printer: Different FDM printers
Material: PET-g
Time spent: 8 to 12 hours
